This week has been more of the same.  Nothing has really changed at Pasadena’s PWP DC Fast charging facilities.

Del Mar – 1 DCFC – on app, there are two DC Fast chargers, only one appears to work consistently. These are older Tritium chargers where only one connector can be used at a time.

Robinson Park – 5 DCFC – on app – update – only 2 working. Which is NO change from from what has been the case for many weeks. – the signage has still not been updated, the chargers are still showing that one can use both sides of the charger.

Victory Park – 3 DCFC – on app, two appear to be working at this time, which is one more than last week. But the third is on, and is not responding.

Glenarm(Arroyo Electric Vehicle) –  2 DCFC on app, appears that several are off and not showing on app. None of the chargers appear to be working.

Marengo Plaza – 20 DCFC on app, will have to go and see, someone reported that you can park for an hour with paying, but I don’t believe this is true, we will inquire and see what we find out If these chargers work, then be able to park for one hour without paying would certainly help.  Even 30 minutes would be helpful for those trying to charge.

Shoppers Lane  – spent some time here, these are all CCS chargers with dual port 150kW capability but nobody is seeing even close to this.  At least have of the ports are inoperable or chargers are turned off.  Connectors are broken, credit card machines are not working.

So of the six locations where Pasadena PWP has DC Fast charging, we don’t know where to rank any of them, but we know they are still in very bad shape,  Promises from PWP have not delivered the half of broken chargers working. Unless all the chargers are Marengo Plaza are working which I highly doubt. That would be the only way that half of the chargers would be working. What the city should do is pull out half of the chargers at Marengo and place the working ones at Victory Park and Robinson Park and Del Mar, to get the maximum working chargers to the community.  Having a large number of chargers on a rooftop parking is a disservice to the community.

And the cost needs to be addressed, at .15 nonpeak and .20 peak, these costs are below what anyone would pay. They need to be more competitive but they also need to work.  Free is great too but if they don’t work and they cannot be supported what good is it.

As usual Tesla chargers work, from what I have seen in the past week, there’s been maybe 2-3 out of the dozens of superchargers that are not working.

Gravity 500kW DC Fast Charging Stations Coming to Southern California including East Pasadena in 2025

Gravity is expanding in the Los Angeles area with several locations coming online in 2025.

The differentiator is the charging level of 500kW which is significantly higher than the majority of chargers available including Tesla which offers 250kW at the vast majority of their Superchargers.

Not much has changed since the last update.  Actually maybe worse.

We are going to focus on this update with what is happening at Victory Park and Robinson Park as those are indicative of what is happening at the dozens of other DC Fast chargers around the city of Pasadena owned and operated by Pasadena.

At Victory Park, only one of three DC Fast chargers was working, although all three are powered on, two of the three either return errors or do nothing, and when you attempt to use the app, they show as not available, some have reported that using a credit card sometimes works, but even the card readers are either damaged covered or show connection failure.

Over at Robinson Park the situation is similar. Two of Five DC Fast chargers work, the PowerFlex app shows that five chargers are available at this location, but only three have power. One of the three does not work. Two work, this has not changed in weeks or months, although some have reported that technicians have been to the location and have done some work.

What has been done appears to be some marking of the power conduit from the street.   Also, the parking spots have been painted with the Charge Up logo, but still there are no signs that these spots are reserved for EV Charging ONLY, and a time limit. And the city fails to acknowledge that there should be a time limit, perhaps 30 minutes and that overstay fees should be substantial to encourage people to let others charge. These are basics when it comes to operating EV Charging. Why Pasadena doesn’t follow is a mystery.

In addition the city has one of the lowest charges for EV Charging, many comment on this, to the point that for many it is less expensive to charge at the PWP EV chargers than at home… that should not be happening.

Also, by having rates so low, it discourages others from either installing chargers, and those with for instance a Tesla will go to the PWP chargers and tie up spaces where the can go and use the Tesla chargers and non-Tesla may not be able to.

These are some serious concerns in addition to the issues with most of the DC Fast chargers not working. It leaves PWP DC Fast charging in a failure state.  We hope the leadership at PWP and Pasadena City government will realize that what is happening is unacceptable and that things have to change.

We will report an update later this week.

If you are a resident of Pasadena or nearby or work in Pasadena, and have tried to use PWP DC Fast chargers and have been frustrated please let the city know.

Fed up with the dismal state of
EV charging in Pasadena.

Demand Change!

Most PWP DC Fast chargers

DO NOT WORK

and have NOT worked for A LONG TIME

(While Tesla chargers WORK!)

Millions of your tax $$$ have been spent!

                              SCAN:

Call and Email :

David Reyes, PWP Manager

(626) 744-7598 davidreyes@cityofpasadena.net

Susana Castro, PWP Senior Executive Assistant

626-744-7029 scastro@cityofPasadena.net

Victor Gordo Mayor

(626) 744-4111  vgordo@cityofpasadena.net

Vannia de la Cuba, vdelacuba@cityofpasadena.net

Miguel Márquez, City Manager

(626) 744-4333 miguelmarquez@cityofpasadena.net

Call the City Service Center and report (626) 744-7311

Call and email your local councilmembers and email city council correspondence@cityofpasadena.net

As of May 1, 2025

We are going to focus on chargers with Chademo for this update.

First the good news:

It does appear that the DC Fast chargers are now showing on the PowerFlex app.  The questions remains do they work.

The bad news after visiting the Robinson Park location, the same chargers are broken with old signs, nothing has changed.  We assume the same is true for other locations, but we could charge on one DC Fast Charger at Robinson Park. So one out of 5, 20% is not good.  Maybe a second one worked but the charger was being used by another vehicle and the signs on the chargers are inaccurate that charging is possible on both ports, and it is not.

Del Mar – 1 DCFC – on app

Robinson Park – 5 DCFC – on app – update – only 2 working. Which is NO change from from what has been the case for many weeks.

Victory Park – 3 DCFC – on app

Glenarm(Arroyo Electric Vehicle) –  2 DCFC on app

Marengo Plaza – 20 DCFC on app

This would mean that if all these chargers are working the total available 50Kw chargers available in Pasadena is 31 that support Chademo and CCS.   The number would be higher for just CCS.

I am leaving off Shopper’s Lane as none of the chargers at this site support Chademo.

As many of you know the current state of DC Fast Charging in Pasadena with PWP chargers is not good, with the majority of the DC Fast Chargers NOT WORKING.

As of April 28, 2025

Del Mar – 2 DCFC – both appear with CCS only one works with Chademo, not usable simultaneously

Robinson Park – 5 DCFC – Two appear to work CCS and Chademo, A third is on but not working. Two others are off. Credit card readers are mostly broken.

Victory Park – 3 DCFC – None appear be working

Glenarm(Arroyo Electric Vehicle) –  6 DCFC none working, all DCFC OFF

Shoppers Lane –  11  – these are all CCS no Chademo available, Hard to know what’s working, reports are maybe a couple are working.

Marengo Plaza – 19 DCFC – a couple appear to be working, I have only seen one car charging on the end unit, all other units appear to be display errors or not on, several others are on, 16 are either off or blocked by barricade, cones

City of Pasadena PowerFlex app, is only showing DC Fast Chargers at Del Mar(1) and Victory Park (3)  so basically according to the app that City of Pasadena relies on and tells users to use, there are four DCFC,  Of those four maybe one is working.  If there are 46 DCFC and half are supposed to be fixed and working by the end of the month, the we should expect to see at least 23 working DC Fast Chargers.  That’s total, not taking into account those the city claims had been previously working. If we take all as not working.  If the city is now deciding to rip and replace chargers that would certainly be a new development and a request will be made when we see signs of that, as there are other operators with the same chargers that are having no problem with the chargers.  EVCS is one local company that is able to display the Tritium chargers and maintain the connection on those chargers. The mess with PowerFlex and Tritium has reached a new level and the cost to users attempting to use them and financial cost to the city will have to be revealed.

The city has stated there are 49 DC Fast Chargers but from what we can tell there are 46, where are the other three?  Are they in a private city lot?

The city of Pasadena Interim PWP manager has stated that half of the “broken” chargers would be repaired and operational by the end of April, which is two days.  We will report on May 1 to see what the status is.

*Slate Truck is currently in preproduction; vehicle specifications and pricing are subject to change. Projected range estimates are based
upon an approximation of the EPA test cycle and are not oBicial EPA estimated range values. Review IRS website to determine eligibility
for potential incentives. Target pricing excludes taxes and fees.
press@slate.auto
Radically Customizable and A4ordable, Beautifully Simplified:
The Slate Truck Redefines Personalized Transportation
• Slate serves the consumer good. Slate is a new American company founded on a disruptive
business model of simplifying the manufacturing process and removing unnecessary content to
reduce cost and increase reliability.
o “The definition of what’s a9ordable is broken,” said Slate CEO Chris Barman. “Slate
exists to put the power back in the hands of customers who have been ignored by the auto
industry. Slate is a radical truck platform so customizable that it can transform from a 2-
seat pickup to a 5-seat SUV.”
• The Slate Truck is a beautifully simplified EV 2-seat pickup, produced in a single configuration
from the factory. Approachable and timeless. Steel wheels outside. Crank windows and HVAC
knobs inside. Large Frunk along with a spacious cargo area with 1400-lb. payload.
• Unlimited personalization, powered by DIY. Slate vehicles are about accessible personalization.
Select from over 100 accessories, available individually or bundled, to make a Blank Slate yours – at
time of purchase or as your needs change over time.
• The truck can be anything – even an SUV. The flat-pack accessory SUV Kit turns the truck into a 5-
seat SUV, with a roll cage, airbags, rear seat. Do it yourself or have it done for you.
• Designed to be wrapped. By you or a pro. Three levels of vehicle wrapping make personalization
far more aRordable. Wrap, unwrap, rewrap for diRerent, inventive looks.
• Bring your own tech. Rather than learn a new interface, use the one you love. Slate introduces the
universal phone mount and USB power. Add a dedicated tablet if you want to.
• An EV for everyone. 52.7-kWh battery pack, 150 kW, rear-wheel drive, range target of 150 miles.*
An accessory 84.3-kWh pack has a target of 240 miles.* Using the NACS port, charge overnight for
your commute on a household outlet, or fast-charge to 80% at 120-kW in under 30 minutes.
• Top occupant safety. Designed to achieve the highest safety ratings. Active Emergency Braking,
Forward Collision Warning, and up to 8 airbags.
• Transparent pricing. Expected price of under $20,000 after federal incentives, making it among the
most aRordable new vehicles.*
• Made in America. Slate will manufacture the truck at a reindustrialized factory in the U.S.,
alongside a Customer Experience Center.
• Direct-to-consumer sales and a nationwide service network. Order your truck online, take
delivery near your home, and find service locations in your neighborhood.
• Refundable vehicle reservations open now at $50. Visit slate.auto to secure yours.
press@slate.auto
Specifications
Vehicle specifications are subject to change. Projected range estimates are based upon internal testing
and an approximation of the EPA test cycle.
Dimensions
Length 174.6 in.
Wheelbase 108.9 in.
Width (w/o mirrors) 70.6 in.
Height 69.3 in.
Interior volume, pickup/SUV 55.0 ft3 / 80.5 ft3
Cargo volume, frunk/bed/SUV behind seats 7.0 ft3 / 37.0 ft3 / 34.0 ft3
Weights, etc.
Curb weight 3602 lb.
Max payload 1433 lb.
Max towing 1000 lb.
Power, propulsion
Motor, drive wheels* Single motor, RWD
Pack size 52.7 kWh (std.), 84.3 kWh (accessory)
Power 150 kW (201 hp)
Torque 264 Nm (195 lb-ft)
0-60 mph, est. 8.0 sec.
Top speed 90 mph
Charging, range
Onboard charger 11kW
Level 1 AC, 3.6kW, 20-100% 11 hr.
Level 2 AC, 11kW, 20-100% Under 5 hr.
Level 3 DC, 120kW, 20-80% Under 30 min.
Charging NACS
Range, standard/accessory (est.) 150 mi., 240 mi.
Combined city/highway (est.) 96 MPGe
Chassis
Front suspension MacPherson strut
Rear suspension De Dion axle, coil spring
Wheel, tire 17” x 7” steel wheel, 29.5” 245/65R17 tire
Bed
Bed width btw. wheel wells 42.9 in.
Bed width min./max. 50.0 in./54.9 in.
Bed length/tailgate down 60.0 in./81.6 in.
*Permanent-magnet synchronous with hairpin winding, combined water and oil cooling. Gearbox: single speed
w/12.44 gear ratio, open diAerential, w/ integrated park lock

As many have experienced the charging of EV’s in Pasadena has been disappointing, and when it comes to DCFC fast charging it has been horrible.

With most DCFC not working.  Well over 80% do not work.

This has been the case for a long time, even before Shell and the City of Pasadena parted ways, and after millions had been spent.

Greenlots failed on many levels and other cities experienced this well before Shell acquired them, and switched to other providers like Chargepoint, ripping out chargers from Greenlots.

Shell now is attempting again but again failing to deploy a network of chargers.   Buying other companies along the way, basically attempting to eliminate the competition.

This leaves Pasadena with approx 50 DC Fast Chargers, at several locations around the city, most notable is the Marengo plaza parking 5th floor top floor with 20 DCFC with most of them not working.  As of April 19, there was one that appeared to work with a vehicle charging.

Most have the old Shell labels or nothing, others have no signage or QR codes.  The city needs to be clear about what is being doing here, and has failed to do that.

The current status is that we are being told that half of the non functioning chargers will be repaired, whatever that number is we don’t know, since what is defined as not working.

The other half will be repaired within three months.  So in three months we should have working approx 50 DCFC in Pasadena. All with CCS and a good amount with Chademo connections at 50kw charging capability.

Current Status:

DC Fast Charging in Pasadena

Del Mar – 2 DCFC – both appear to with with CCS only one works with Chademo

Robinson Park – 5 DCFC – 2 working, both on CCS and Chademo

Victory Park – 3 DCFC – 1 working – only CCS.  2 others are on, but either QR code is incorrect or units are broken, even though city claims all units are operations.

Glenarm(Arroyo Electric Vehicle) –  6 DCFC none working, all DCFC OFF

Shoppers Lane –  possibly 2 are working  only CCS  chargers

Marengo Plaza – 20 DCFC – 1 appears to be working, several others are on, 16 are either off or blocked by barricade, cones

City of Pasadena PowerFlex app, is only showing DCFC at Del Mar(1) and Victory Park (3)  so basically according to the app that City of Pasadena relies on and tells users to use, there are four DCFC,  Of those four two work from what we can tell.

With less than two weeks for the city to repair the broken DCFC we certainly hope the city can deliver on the repairs of these chargers.

One continued comment we hear is that the rate for charging on Pasadena PWP chargers is one of the lowest.  I don’t think that is a good thing.  The city needs to figure out a competitive rate, and perhaps seriously revise rates, but also one thing that needs to be done is offer residents a preferred rate.  Also, the limit on DCFC should be 30minutes max.  There’s no reason anyone should be there longer, if they do, there needs to be surcharges.  If a charger is still available after 30minutes you can either restart a session, or move to another charger or move and allow someone else 30minutes of charge. When there are multiple vehicles attempting to charge like is common at Robinson Park, there needs to be a way to que vehicles and allowing others to charge.

Right now it seems that Robinson Park needs the most attention to chargers.  With 5 chargers and only two working, if the city could double that quickly it would really help the users.

As many Altadena residents who lost their homes have told me firsthand, they rely on fast charging, to get back and forth, many live far away and fast charging is the only viable way to get back and forth from their current housing.

The city sends people to this page:

Find an Electric Vehicle Charging Station

Then sends them to Plugshare.  Notice that Robinson Park is not listed on the city website. Why?
